Hygienic Washdown
Friction Feeder 300

Hygienic Feeder, CIP Design for Reduced Risk of Contamination

The Hygienic Washdown Feeder 300 meets sanitary requirements and complies with IP66 or higher as well as NEMA4X standards. The hygienic friction feeder is designed for end-customers in the food industry that need to repetitively and aggressively clean their production floor equipment. This clean in place (CIP) friction feeder is engineered with type 304 stainless steel, powered by a 1200 watt brushless servo motor, and is moisture and corrosion resistant and meets FDA standards. The open design allows for minimal disassembly for easy cleaning and maintenance. This machine is self-draining and has compatible materials with no hollow areas, which is a principle we follow to ensure the sanitary design and reduced risk of contamination.

Typical Applications:
Hygienic Washdown Feeder 300

  • Insertion into a catch-tray, box or conveyor
  • Deliver a product to a secondary application
  • Batching, high speed tipping or affixing, collating systems and barcode/vision systems

Hygienic 300 Typical Products that feed:

  • Minimum product size: 25mm(W) x 40mm(L)
  • Maximum product size: 300mm(W)
  • Minimum product thickness: 0.075mm
  • Maximum product thickness: 25mm
  • Maximum belt speed: 140 meters/min
  • Operating temperature: 2-35 degrees C [35-95 degrees F]
  • Power requirements: 110/220 volts 50-60 Hz max 6 Amps
